High Barrier PET Film Moisture-Proof Oil-Proof for Industrial & Food Use
WhatsApp: +86 15065872595
Email: sale@sdzlplastic.com
Product Description

Core Features

  • Exceptional Mechanical Performance: High tensile strength, good toughness, and excellent dimensional stability, resistant to tearing and deformation even in harsh environments.
  • Superior Thermal Stability: Can withstand a wide temperature range (-40℃ to 120℃), maintaining stable performance without melting or brittleness, suitable for high-temperature processing and storage.
  • Optical Properties: Clear PET film boasts high transparency (≥90%) and glossiness; matte PET film has uniform haze for anti-glare effect; black PET film offers high coverage and opacity.
  • Chemical Resistance: Resistant to water, oil, acids, alkalis, and most organic solvents, ensuring no deformation or deterioration when in contact with various substances.
  • Eco-Friendly & Safe: Non-toxic, tasteless, compliant with FDA, EU, and other international food contact standards, recyclable to support environmental sustainability goals.
  • Customizable: Thickness, width, length, surface treatment (corona, anti-static, anti-fog), and color can be customized according to customer requirements.
  • Excellent Insulation: Particularly for black and clear PET films, offering good electrical insulation performance, suitable for electronic and transformer insulation applications.

Technical Specifications (Standard & Customizable)

Item
Standard Specification
Customizable Range
Test Method
Material
100% Polyethylene Terephthalate (PET)
Food Grade / Industrial Grade PET Resin
ASTM D4603
Thickness
12μm - 200μm
6μm - 500μm
GB/T 13542.2-2009
Width
500mm - 2500mm
300mm - 3000mm
Manual Measurement
Length
100m - 1000m/roll
50m - 2000m/roll
Manual Measurement
Transparency (Clear Film)
≥90%
≥85% - ≥95%
ASTM D1003
Haze (Matte Film)
45% - 75%
30% - 80%
ASTM D1003
Tensile Strength (MD/TD)
≥150MPa / ≥160MPa
120MPa - 200MPa
ASTM D882
Elongation at Break (MD/TD)
≥110% / ≥90%
80% - 150%
ASTM D882
Heat Shrinkage (150℃, 15min)
≤1.5% (MD) / ≤1.0% (TD)
≤0.5% - ≤2.0%
Lab Test
Dielectric Strength
≥70V/μm
60V/μm - 100V/μm
ASTM D149-64
Water Vapor Transmission Rate (WVTR)
≤3.5g/(m²·24h)
≤1.5g/(m²·24h) - ≤5.0g/(m²·24h)
GB/T 21529-2008
Color
Clear, Matte, Black, White
Custom Color (Blue, Red, Yellow, etc.)
Visual Inspection
Surface Treatment
Corona Treatment (≥52mn/m), Anti-Static
Chemical Treatment, Anti-Fog, Anti-Scratch
GB/T 14216-2008

Application Fields

  • Packaging Industry: Food packaging (snacks, candies, beverages, frozen food), pharmaceutical packaging, cosmetic packaging, blister packaging, and flexible packaging. It provides excellent moisture-proof, oil-proof, and barrier properties to extend product shelf life.
  • Electronic Industry: Protective films for mobile phones, tablets, and other electronic devices (anti-scratch, anti-fingerprint), insulation films for motors, transformers, and electronic components, and substrate films for circuit boards.
  • Printing & Label Industry: High-gloss PET film for offset printing, gravure printing, and silk-screen printing, label base films (barcode labels, product labels) with good printability and adhesion.
  • Industrial & Insulation: Black PET film for drum skin, R-type transformer outsourcing, and insulation tapes; metallized PET film for decorative materials and reflective applications; cavitated PET film for packaging with excellent dead fold performance.
  • Other Fields: Solar cell backplane substrates, textile and apparel packaging, glass protection films, and recyclable strapping tapes as an eco-friendly alternative to PVC or PP tapes.

Packaging & Shipping (For Foreign Trade)

  • Packaging: Each roll is wrapped with moisture-proof PE film, then packed in a wooden pallet or carton, with foam padding to prevent damage during transportation. Custom packaging is available according to customer requirements (such as export standard packaging).
  • Shipping: Ocean, air, and land transportation are available, with professional loading to ensure the safety of goods. We cooperate with well-known international logistics companies to provide timely and efficient delivery services to global ports (e.g., US, EU, Southeast Asia, Middle East ports).
  • MOQ: 200kg - 500kg (depending on product type and specifications), with preferential prices for bulk orders.
  • Lead Time: 7-15 working days for standard products; 15-25 working days for customized products.

Quality Assurance

Our PET Film strictly complies with international standards such as ASTM, FDA, EU, and GB, with a complete quality control system from raw material selection to production, testing, and packaging. Each batch of products undergoes strict inspection (thickness, transparency, tensile strength, etc.) before delivery to ensure stable quality and consistent performance. We also provide quality certificates and test reports to meet the import requirements of different countries and regions.
